Overview

PAC Blocks are manufactured from Autoclave Aerated Concrete (AAC). This is made from lime, sand and Cement, to which a frothing agent Aluminum powder is added to aerate the Concrete. The partially cured concrete is then autoclave to complete the curing and to promote the formation of a crystalline structure. The aeration and low density (Approximately one quarter of the density of standard Reinforced concrete) enables blocks to be easily cut, drilled and shaped by hand. Blocks are glued together to form solid Masonry structural walls with excellent thermal and acoustic Properties.

Technical Specification

		Load-bearing Panel
Density grade		PAC - 4	PAC - 6
Mean Compressive Strength (MPa)		5	7.5
Mean dry density (kg/m3)		500 - 600	600 - 700
Mean working density (kg/m3)		600 - 700	700 - 800
Dry thermal conductivity [ W/(m2 k)]		≤0.13	≤0.15
Dry shrinkage (mm/m)		≤0.02
Shrinkage Strain	/°C	200x10-6
Dry shrinkage (mm/m)	/°C	8.1x10-5
Modulus of Elasticity	N/mm2	2330	2970

Product Dimensions and Packing

Thickness (mm)	Height (mm)	Length (mm)	Pieces Per Pallet	Pallet volume (m3)
50	200	600	140	1.80
100	200	600	150	1.80
150	200	600	100	1.80
200	200	600	70	1.68*
200	200	600	70+10	1.80**
250	200	600	60	1.80
300	200	600	50	1.80
375	200	600	40	1.80
50	250	600	240	1.80
100	250	600	120	1.80
150	250	600	80	1.80
200	250	600	54	1.68
250	250	600	48	1.80
300	250	600	40	1.80
375	250	600	32	1.80
